Motor has the function of 10-120 RPM stepless speed regulation and automatic lifting , revolving consists of a set of stable and reliable micro motor, speed motor and integrated circuit control device. In the role of electronic speed, it can rotating steadily in 10-120 RPM range, it has reached the advanced level at home and abroad.
1. Quick and easy lifting mechanism.
2. Evaporator along the horizontal direction can lean in 0-45 ℃ arbitrarily.
3. Vertical condensation system of high rate of evaporation.
4. Vacuum sealing way.
5. Automatic control temperature digital display.
SPECIFICATIONS
| Specification | Model | 4107-LRE-52C |
| Glass material | GG-17 | |
| Frame material | Aluminium alloy | |
| Pot shell Material | Aluminium alloy 250*365*150mm | |
| Pot bravery material | Stainless steel 240*120mm | |
| Evaporator flask | 1L 24# | |
| Collect flask | 0.5L 24# | |
| Vacuum degree | 0.098Mpa | |
| Rotary power | 30W | |
| Rotary speed | 0-120rpm | |
| Heating power | 1KW | |
| Heating temp.range | 0-99℃ | |
| Temp. accuracy | ±1℃ | |
| Lifting disctance | 120mm | |
| Voltage | 220V/50Hz | |
| Dimension(mm*mm*mm) | 700*440*1005 | |
| Packing size(mm*mm*mm) | 590*460*460 | |
| Packing weight（KG） | 21 | |
| Configuration list | Speed mode | Electronic stepless |
| Temp. display | CU50 sensor with digital display | |
| Temp. control | Intelligent temp. control | |
| Sealing method | PTFE sealing | |
| Condenser | Vertical condenser 85*460mm 29# | |
| Lifting mode | Electric automatic lifting | |
| Continuous feed | 19# feed valve | |
| Optional | Anti-Splash device | Transparent cover for heating bath |
| Bath temp.range | 0-400℃ |
