Product Description
Key Features
- Made of 100% virgin-grade fluorinated ethylene propylene (FEP)
- Excellent chemical and thermal resistance
- Great optical clarity—easily view your sample in use
- Sterilize by autoclave, EtO, and chemical sterilants
- Complies with FDA 21 CFR 177.1550, USP Class VI, NSF 51, NSF 61, NSF 372, and ASTM D2116
- Ideal for general-purpose, laboratory, and single-use applications
- Free technical application support available to assist with tubing selection
- Manufacturer defect warranty
More About this Item
FEP fluoropolymer tubing in pharmaceutical, food, and laboratory applications. This chemically inert tubing offers excellent resistance to a broad range of solvents, bases, and strong acids and exhibits high thermal stability.
The nonstick property and low permeability help reduce the absorption/adsorption of fluids, minimizing the risk of fluid contamination. Optically clear tubing makes it easy to view your fluid for sight gauge and flow applications.
Warning: This product is not approved or intended for, and should not be used for, medical, clinical, surgical or other patient-oriented applications.
Specifications
- Tubing Formulation FEP
- Clarity (clear)Yes
- Working Pressure (bar)20.4
- Max Working Pressure at 73 F (PSI)296
- Max Temperature (° F)400
- Max Temperature (° C)204
- Length (ft)50
- Sterilization Method Autoclave; EtO
- Regulatory Approvals NSF-51; USP; FDA; RoHS; ADCF; NSF-61
- Durometer 60 Shore D
| Cat No. | Tubing ID (in) x Tubing OD (in) | Wall Tickness | Max Tempc |
|---|---|---|---|
| 5664-15 | 1.6mm, 1/16″ ID x 3.2mm, 1/8″ OD | 0.8mm – 1/32inch | 204c / 400f |
| 5664-16 | 2.4mm, 3/32″ ID x 4mm, 5/32″ OD | 0.8mm – 1/32inch | 204c / 400f |
| 5664-17 | 3.2mm, 1/8″ID x 4.8mm, 3/16″OD | 0.8mm – 1/32inch | 204c / 400f |
| 5664-18 | 3.2mm, 1/8″ID x 6.4mm, 1/4″ OD | 1.6mm – 1/16inch | 204c / 400f |
| 5664-19 | 4.8mm, 3/16″ID x 6.4mm, 1/4″OD | 0.8mm – 1/32inch | 204c / 400f |
| 5664-20 | 4mm, 5/32″ID x 6.4mm, 1/4″OD | 1.2mm – 3/64inch | 204c / 400f |
| 5664-23 | 11mm, 7/16″ID x 12.7mm, 1/2″ OD | 0.8mm – 1/32″inch | 204c / 400f |
| 5664-24 | 12.7mm, 1/2″ID x 14.3mm, 9/16″OD | 0.8mm – 1/32″inch | 204c / 400f |
| 5664-83 | 0.8mm, 1/32″ID x 1.6mm, 1/16″OD 1/32 |
FEP PTFE Tube ID 0.5 1 2 2.5 3 4 5 6 7 8 10 12 14 16 18 20 mm PTFE/F46 Insulated Rigid Pipes 600V For 3D Printer Parts Pipe 3KV
| 5664-1 | ID 0.5mm x 1mm OD | FEP/PTFE, Temp. 260c | Length: 1meter | |
| 5664-2 | ID 1mm x 2mm OD | FEP/PTFE, Temp. 260c | Length: 1meter | |
| 5664-3 | ID 2mm x 3mm OD | FEP/PTFE, Temp. 260c | Length: 1meter | |
| 5664-5 | ID 2m x 4mm OD | FEP/PTFE, Temp. 260c | Length: 1meter | |
| 5664-6 | ID 2.5mm x 4mm OD | FEP/PTFE, Temp. 260c | Length: 1meter | |
| 5664-7 | ID 3mm x 4mm OD | FEP/PTFE, Temp. 260c | Length: 1meter | |
| 5664-8 | ID 3mm x 5mm OD | FEP/PTFE, Temp. 260c | Length: 1meter | |
| 5664-9 | ID 4mm x 5mm OD | FEP/PTFE, Temp. 260c | Length: 1meter | |
| 5664-10 | ID 4mm x 6mm OD | FEP/PTFE, Temp. 260c | Length: 1meter | |
| 5664-11 | ID 5mm x 6mm OD | FEP/PTFE, Temp. 260c | Length: 1meter | |
| 5664-12 | ID 5mm x 7mm OD | FEP/PTFE, Temp. 260c | Length: 1meter | |
| 5664-13 | ID 6mm x 8mm OD | FEP/PTFE, Temp. 260c | Length: 1meter | |
| 5664-14 | ID 7mm x 9mm OD | FEP/PTFE, Temp. 260c | Length: 1meter | |
| 5664-15 | ID 8mm x 10mm OD | FEP/PTFE, Temp. 260c | Length: 1meter | |
| 5664-25 | ID 8mm x 12mm OD | FEP/PTFE, Temp. 260c | Length: 1meter | |
| 5664-26 | ID 10mm x 12mm OD | FEP/PTFE, Temp. 260c | Length: 1meter | |
| 5664-27 | ID 12mm x 14mm OD | FEP/PTFE, Temp. 260c | Length: 1meter | |
| 5664-28 | 14 x 16, 0.5M X 2pcs | FEP/PTFE, Temp. 260c | Length: 1meter | |
| 5664-29 | 16×18, 0.5M X 2pcs | FEP/PTFE, Temp. 260c | Length: 1meter | |
| 5664-30 | 18 X 20, 0.5M X2pcs | FEP/PTFE, Temp. 260c | Length: 1meter | |
| 5664-31 | 20×22, 0.5M X 2pcs | FEP/PTFE, Temp. 260c | Length: 1meter | |
