Oven Prime Range – Digital – PRO/TDIG


 The GENLAB range of Prime Ovens are the flagship brand of Genlab Ovens. They are built to the highest standards and packed with many features and enhancements. As standard, the Prime range offers a heavy duty stainless steel interior, increased accuracies on our standard models and are quicker responding. This range can offer increased load capability, multiple reinforced shelves and operate at 300 ºC continuously. It features our latest touch screen control system which offers intuitive control, designed for industrial and laboratory ovens.
 Prime Oven DesignThe exterior is constructed from sheet steel finished in an easy clean powder coated paint.

The interior chamber is made from stainless steel.

The units are fitted with fixed shelf runners and removable chrome plated wire grid shelves.

Prime Oven Heating

The units are heated by Incoloy sheathed elements positioned around the fan fitted at the back of the chamber.

Prime Oven Controls

The control system comprises of a bespoke touch screen interface that offers both accurate temperature control and an integral overheat system by using 2 individual Pt100 sensors. Advanced features can be turned on and off to suit bespoke heating applications and tailored to customer preference. Oven trending is displayed for up to 48 hours and optional upgrades are available for alarm outputs.
 Specifications

  • 7 sizes 30 to 200 litres
  • Stainless Steel Internal Chamber
  • Temperature range: 40ºC to 250ºC (300ºC option)
  • On screen historical trending (48 hours)
  • Count down timer
  • 24/7 real time clock operation
  • Manual or automatic overheat reset
  • High accuracy Pt100A duplex sensor <0.6ºC
  • Fan assisted circulation
  • Excellent stability <+/- 0.5ºC
  • Low chamber uniformity
  • Quick responding
   Options

  • 300ºC Continuous temperature rating
  • Reinforced shelving (upto 40KG)
  • Reinforced total load
  • Access ports (25, 50, 75 or 100mm)
  • Traceable calibrations to national standards
  • Bespoke standads and stacking kits
  • Extractor Unit
  • Audible warnings
  • Extended warranty
  • Bespoke solutions available upon request
 Prime Oven Specifications

Genlab ref.
Number
Capacity
(litres)
Internal dims.
(H x W x D cms)
External dims.
(H x W x D cms)
No. of
Shelves
No. shelf
positions
Wattage/
Voltage
Weight
(kg)
PRO/30/TDIG
30
24 x 36 x 31
57 x 50 x 62
2
2
1000/230
30
PRO/50/TDIG
53
33 x 49 x 29
66 x 63 x 59
2
3
1000/230
40
PRO/75/TDIG
73
33 x 49 x 41
66 x 63 x 72
2
3
1500/230
60
PRO/100/TDIG
99
45 x 49 x 41
78 x 63 x 72
3
4
1500/230
70
PRO/125/TDIG
120
55 x 49 x 41
88 x 63 x 72
3
5
2000/230
75
PRO/150/TDIG
143
55 x 49 x 49
88 x 63 x 80
3
5
2000/230
80
PRO/200/TDIG
195
75 x 49 x 49
108 x 63 x 80
4
7
2500/230
105

Ordering

All units have a stainless steel interior, forced convection and a touch screen interface with all the timer features enabled as standard. Where options are required, simply add the option code to the original reference.

E.g.PRO/50/TDIG with extended temperature range and an audible warning becomes PRO/50/TDIG/300/AWA

Contact sales for bespoke options

  Option codesTemperature 40ºC to 300°C – 300
Access Ports – AP
Traceable Calibration – SPC
Temp Uniformity Surveys – TUS
Extraction Systems – EXT
Audible Warnings – AWA
Extended Warranty – X1
